Product Description
Function/advantages of rock wool
Heat Insulation and Thermal Preservation
Low conductivity factor
Noise Insulation and Sound Absorption
Water Proof & Moisture Proof
Stable physical and chemical properties.
Antisepsis, ageing resistance, and anticorrosion, ensuring a healthy environment
Easy for construction.
It can not only be applied to smoke resistance between curtain wall and floor or curtain wall and neighboring wall but also be applied to other construction gaps including pipe gas.In order to reinforce the ability to resist smoke,fireproof aluminum foil is plastered onto the surface of rock wool panels.
The product is mainly used to prevent fire in the curtain wall system.Its excellent heat preservation performance can effectively reduce heat transmission.The aluminum foil and other decorative material can be applied to the surface of rock wool panels.
Technical Data
Product Application
(1) Petrochemical industry -- heat insulation and sound absorption of equippments for petroleum industry, power industry and chemical industry.
(2) Construction industry -- heat insulation and sound absorption of partition, curtain wall, roofs and fences for construction.
(3) Mining industry -- heat preservation and fireproof for industrial kiln, oven, large-caliber storage tank and shipping.
Function/advantages of rock wool
Heat Insulation and Thermal Preservation
Low conductivity factor
Noise Insulation and Sound Absorption
Water Proof & Moisture Proof
Stable physical and chemical properties.
Antisepsis, ageing resistance, and anticorrosion, ensuring a healthy environment
Easy for construction.
It can not only be applied to smoke resistance between curtain wall and floor or curtain wall and neighboring wall but also be applied to other construction gaps including pipe gas.In order to reinforce the ability to resist smoke,fireproof aluminum foil is plastered onto the surface of rock wool panels.
The product is mainly used to prevent fire in the curtain wall system.Its excellent heat preservation performance can effectively reduce heat transmission.The aluminum foil and other decorative material can be applied to the surface of rock wool panels.
Technical Data
| Product Code | GF-WQ1 | GF-WQ2 | GF-WQ3 |
| Density kg/m3 | 40-80 | 80-120 | 120-180 |
| Thickness (mm) | 40-150 | ||
| Size (mm) | 1200 X 600 | ||
| Product Performance | GF-WQ1 | GF-WQ2 | GF-WQ3 | Unit | Standard |
| Compressive Strength | ≥40 | ≥60 | ≥80 | K Pa | EN826 |
| Tensile Strength | ≥7.5 | ≥10 | ≥15 | K Pa | GB/T 149-2003 |
| Thermal Conductivity (25ºC) | ≤0.040 | W/(m.k) | GB/T 10295 | ||
| Fire Protection | Incombustible Material A | Level | GB 8624-2007 | ||
| Acidity Coefficient | ≥1.8 | ------- | GB/T 5408 | ||
| Moisture Resistance | ≥99 | % | GB/T 10299 | ||
| Mass Humidity Absorption | ≤1.0 | % | GB/T 5480 | ||
| Moisture Absorption ( 24h) | ≤0.5 | Kg/m³ | GB/T 25975-2010 | ||
| Moisture Absorption ( 28d) | ≤2.0 | Kg/m³ | GB/T 25975-2010 | ||
| Size Stability | ≤1.0 | % | GB/T 8811 | ||
| Melting temperature | ≥ 1000 | ºC | DIN4102-17 | ||
Product Application
(1) Petrochemical industry -- heat insulation and sound absorption of equippments for petroleum industry, power industry and chemical industry.
(2) Construction industry -- heat insulation and sound absorption of partition, curtain wall, roofs and fences for construction.
(3) Mining industry -- heat preservation and fireproof for industrial kiln, oven, large-caliber storage tank and shipping.
(4) Our product is widely used for the heat insulation and sound absorption and heat preservation of pipes in building field.
